GENERAL
| Item |
Details |
| Service |
Echo Factory |
| Frequency Range |
245.0000 – 246.9875 MHz |
| Frequency Stability |
±2.5 ppm |
| NBTC ID |
B50004-20-0990 |
| Display |
Single standby |
| Languages |
English & Chinese voice prompt |
| Protection Standard |
None |
| Memory Channels |
160 Channels |
| CTCSS |
50 Tone |
| DCS |
83 Tone |
| Channel Step |
12.5 KHz / 25 KHz |
| Working Voltage |
7.4V ±20% |
| Battery Capacity |
1,500 mAh |
| Average Battery Life |
12 Hours |
| Antenna Impedance |
50 Ohm |
| Dimensions (H×W×D) |
2.5 × 5.5 × 11.5 cm (with Battery) |
| Weight |
200 g |
Transmitter
| Item |
Details |
| RF Output Power |
5W |
| Frequency Deviation |
±4.5 kHz |
| Spurious Emissions |
-36 dBm <1GHz |
| Adjacent Channel Power |
60 dB |
| Audio Response |
+1 / -3 dB |
Receiver
| Item |
Details |
| Sensitivity |
0.18 µV |
| Selectivity |
≤65 dB |
| Intermodulation |
60 dB |
| Spurious Rejection |
70 dB |
| Hum & Noise |
-40 dB |
| Audio Power Output |
1,000 mW |
| Audio Distortion |
<5% |
